Bildiagnostikk iObd2 for iPhone WiFi
Bildiagnostikk iObd2 for iPhone WiFi
Bildiagnostikk iObd2 for iPhone WiFi
Bildiagnostikk iObd2 for iPhone WiFi

Bildiagnostikk iObd2 for iPhone WiFi

kr 799
Produktet er utløpt
  • Frakt 49 kr
  • Sikkerhet - 4,4 av 5 stjerner på Trustpilot
  • Trygghet - 30-dagers prisgaranti - Over 1 million fornøyde kunder
  • Priser inkl. tollavgift og mva
  • prisjakt


Beskrivelse

Bildiagnostikk OBDII for din iPhone eller Android mobil.
Lade hjem App gratis og kommunisere trådløst via WiFi med din bil.
Du kan lese av Motor hastighet, motortid, drivstoff korrigering, drivstoff forbrukning, kjøler temperatur og mye mer.

NB! Ikke noen support gis på dette produkt, all bruk av bildiagnostikk-verktøy skjer på egen risiko...

Introduction of iobd2
iOBD2 is a vehicle diagnostic tool which developed for car owners. It is for iPhone and Android phones and it communicates with these smart phones by WIFI. It supports OBDII/EOBDII. It records the data by the client software of the phone. It records data like engine speed, ignition time, fuel correction, fuel consumption, coolant temperature, when you are driving the car and it shows these data by form or graph format.


Client Software Introduction

Communication
iobd2 communicate with iPhone and Android phones with WIFI

Connection
Input the car models or select the saved car models, then enter the system

Diagnostic Functions
Support vehicles with OBD II/EOBD protocol.
Read DTC
Clear DTC
Read data stream
Read freeze frame data, vehicle information
Oksygen testing,
Mote 6 testing
Evaporative Emission System Leak Detection

My Dashboard
Idle speed mote: control the voltage, intake air flow, real time fuel consumption (static), coolant temperature, spark advance angle, engine speed
Cruise mote: vehicle travel time, average speed, continuous running mileage, average fuel consumption, vehicle speed
Sport mote: vehicle speed, coolant temperature, real time fuel consumption (dynamic), acceleration,engine speed. It is with rich user experience.

Performance Testing
Provide car data and information which you care. For example, acceleration and deceleration test from 0 to 400 meters.

Setting
You can set the speed, mileage, temperature, fuel consumption and you can also configure the data of your dashboard. And you can also set the fuel consumption coefficient between0.9-1.1. Its initial value is 1.



History Record
Save the testing data such as DTC, data stream, freeze frame, and the data of your dashboard for you.

Information
Read the information of iobd2 and can help users do WIFI setting.

UI
Humanity designed UI of the client software which is the same style of the iPhone and Android operation system.

Compatible Phones
Software for iPhone:
compatible with iPhone and iPod OS4.1 versjon or above
Software for Android: compatible with all Android OS phones


Software Download Instructions
Android Version Installation
Install Directly: download APK format files and install it by SnapPea or 91 mobile software
Install by SnapPea Mobile Elf: go to SnapPea Mobile Elf and search iobd2 in Application.Games then you can find it. Just install it, please.
iPhone/iPod touch Version Installation
Install by mobile: visit App Store and search iobd2 then download and install it
Install by iTunes: download and install iTunes, and search iobd2 in iTunes, download and install it.
Install by 91 mobile software: install the downloaded iobd.ipa by 91 mobile software

Accessories
USB cable, iobd2 connector, user manual

Now you do not need to drive on with the MIL light on.
Now you do not need to wait to go to the garage with your car to know what is wrong.
Now you can prepare the garage staff in advance by knowing what is wrong with your car.
Now you can see what is wrong with your car on your holiday so that you know if you can drive on.
Now you can know what your fuel consumption, torque, or acceleration is, in real time.
Now ever wished you had your own customizable gauges, showing only the data you were interested in.

Please verify that your vehicle is OBD-II/EOBD compliant before purchasing!
Get the benefit of multiple gauges without the overwhelming clutter and the expense!
(Note: Not all OBD-II compliant vehicles will have support for all of these parameters)
Performance gauges:
- Engine speed
- Corrected vehicle speed
- Open/closed loop
- Boost/vacuum combo gauge
- Acceleration (and braking)
Fuel economy gauges:
- Inst. fuel economy
- Avg fuel economy
Engine gauges:
- Timing (spark advance)
- Engine coolant temp.
- Intake air temp.
- Ambient air temp.
- Manifold absolute pressure
- Mass air flow
- Fuel trims, short and long term
- Percent engine load
- Catalyst temp.
- Fuel pressure
- Lambda gauge
- Air/fuel ratio

Function:


Diagnostic
The [Diagnostic] function includes:
[Read DTC]: Read the current DTC that engine has stored, and DTC info.
[Clear DTC]: Clear all the current DTC.
[Live data]: Read all the running parameters that related to the ECU.
[Freeze frame data]: OBD system will record the system running parameters related to the malfunction the moment when it occurred at the same time when it set the DTC. And this group of data is called freeze frame data.
[Readiness test]: Readiness reflects the status that all the valid diagnostic functions. The diagnostic functions are referring to the important monitoring functions in OBD system, e.g.
sensor monitoring,
sensor heater monitoring, and EGR system monitoring, etc.. These diagnostic functions are closely related to the engine emission control.

[Read vehicle info]: Read vehicle info such as Vehicle Identification Number(VINCH), Calibration IDs(CALID) and Calibration Verification Number (CVN).
[ Sensor test]: This service is to allow access to the on-board oxygen sensor monitoring test results. The same information may be obtained by the use of [Mote 6 test].
[Mote 6 test]: This service is to allow access to the results for on-board diagnostic monitoring tests of specific components/systems that are not continuously monitored. Examples are catalyst monitoring and the evaporative system monitoring.
[EVAP System Test]: The purpose of this service is to enable the external test equipment to control the operation of an on-board system, test or component.

My dashboard
The [My dashboard] function includes:
[Idle mote]: engine rotational speed ,water temperature,battery voltage,AIR-intake temperature,Instant
fuel consumption ( static),average fuel consumption ,Ever wished you had your own customizable gauges, showing only the data you were interested in

[Cruise mote]: vehicle speed, The current engine load, water temperature, Vehicle travel time, vehicle travel average speed, Continuous running mileage, instant fuel consumption(dynamic),Ever wished you had your own customizable gauges, showing only the data you were interested in.

[Sport mote]: engine rotational speed, vehicle speed, water temperature

Performance test
The [Performance test] function includes:
[Accelerate/Decelerate test]: Test acceleration / deceleration process time and distance
[0 to 400m acceleration test]: test spend time from 0 to 400 meters.

Diagnostic software updating
Users can find out the latest software release info, downloading and installing procedures info by logging on to app store.

History
Record DTC, live data, freeze frame data,my dashboard data. And you can share the record what you get from the car by IOBD2 on Twitter and Facebook.

Emissions Testing:
- Read and clear diagnostic trouble codes
- IM Readiness status

Components
The hardware includes: iOBD2 unit
The software includes: iOBD2 client software,you can source iobd2 software and download it from apple store.
Article number: 31737
